FLASH serii CLH

MODEL

HEAT AREA

HEATING ZONES

HEATING ELEMENT

POWER and TEMPERATURE CONTROL

PREHEAT

FUNCTION

TIME CONTROL

PHOTOSENS. & STAND

CLH 1318

33 x 46 cm

9 kW

3 Horizontal, all possible combination of working

QUARTZ TUBE

9 pcs

Range 5-100%, power line synchronization, can be triggered from panel or automatic machine, Temperature control

Compensates the start-up time, possibility to set step characteristic

From Panel or automatic machine

INCLUDED

CLH 1618

41 x 46 cm

12 kW

3 Vertical, all possible combination of working

QUARTZ TUBE

8 pcs

CLH 2020

pic 1,pic 2

51 x 51 cm

13.5 kW

3 Horizontal, all possible combination of working

QUARTZ TUBE

9 pcs

CLH 2024

51 x 60 cm

18 kW

3 Horizontal, all possible combination of working

QUARTZ TUBE

12 pcs

CLH 2030

51 x 70 cm

21 kW

3 Horizontal, all possible combination of working

QUARTZ TUBE

14 pcs

CLH 2432

pic 1,pic 2,

61 x 81 cm

22.5 kW

3 Horizontal, all possible combination of working

QUARTZ TUBE

15 pcs

CLH 4336

pic 1,pic 2

110 x 91 cm

40 kW

3 Vertical, all possible combination of working

QUARTZ TUBE

20 pcs

Smart Power Management System
